| Camera |
| Shutter Speed |
Bulb Mode
Mechanical Shutter 1/4000 to 30 Seconds |
| White Balance |
Fluorescent (White)
Auto
Cloudy
Daylight
Flash
Shade
Tungsten |
| Camera Format |
APS-C (1.6x Crop Factor) |
|
| Imaging/ Image Sensor |
| Pixels |
Actual: 25.8 Megapixel Effective: 24.1 Megapixel |
| Max Resolution |
24 MP: 6000 x 4000 |
| Aspect Ratio |
1:1
16:9
3:2
4:3 |
| Sensor Type |
CMOS |
| Image File Format |
JPEG
RAW |
| ISO Sensitivity |
100 to 12800 |
| Bit Depth |
14-bit |
| Image Stabilization |
5-Axis (Video Only)
Digital |
|
| Lens |
| Lens Mount |
Canon EF
Canon EF-S |
| Focus Type |
Auto & Manual |
|
| System |
|
|
| Shutter |
| Self Timer |
2/10-Second Delay |
|
| Focus & Optics |
| Focus Mode |
Automatic (A)
Continuous-servo AF (C)
Manual Focus (M)
Single-servo AF (S) |
| Autofocus Points |
Phase Detection: 9 (1 Cross-Type) |
| Autofocus Sensitivity |
-0.5 to +18 EV |
|
| Viewfinder & Display |
| Viewfinder Coverage |
95% |
| Viewfinder Type |
Optical (Pentamirror) |
| Viewfinder Eye Point |
19.00 mm |
| Viewfinder magnification |
Approx. 0.87x |
| Screen type |
Articulating Touchscreen LCD |
| Screen Size |
3″ |
| Diopter Adjustment |
– 3.0 to +1.0 m |
| Screen Resolution |
1,040,000 Dot |
|
| Exposure Control |
| Exposure Modes |
Modes: Aperture Priority, Manual, Program, Shutter Priority |
| Metering Method |
Center-weighted average metering
Evaluative Metering
Partial Metering
Spot metering |
| Metering Range |
1 to 20 EV |
| Exposure Compensation |
-5 to +5 EV (1/3, 1/2 EV Steps) |
| Continuous Shooting |
Up to 5 fps at 24.1 MP for Unlimited Exposures (JPEG)
Up to 5 fps at 24.1 MP for up to 10 Exposures (Raw) |
| Interval Recording |
Yes |
|
| Recording |
| Audio Recording |
Built-In Microphone (Stereo)
External Microphone Input |
| Audio Format |
AAC |
| Recording Modes |
Full HD (1920 x 1080) at 25p/29.97p/50p/59.94p [12 to 60 Mb/s]
HD (1280 x 720) at 50p/59.94p [26 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/25p [120 Mb/s] |
| External Recording Modes |
DCI 4K (4096 x 2160) at 23.976p/29.97p
Full HD (1920 x 1080) at 59.94i/59.94p |
| Recording Limit |
Up to 29 Minutes, 59 Seconds |
|
| Connectivity |
| Wi-Fi Capable |
Yes |
| Connectivity |
3.5mm Microphone, HDMI C (Mini), Micro-B (USB 2.0) |
| GPS |
No |
|
| Flash |
| Built-in Flash |
Yes |
| Dedicated Flash System |
eTTL |
| External Flash Connection |
Hot Shoe |
| Flash Compensation |
-2 to +2 EV (1/3, 1/2 EV Steps) |
| Max Sync Speed |
1/200 Second |
|
| Interface |
| Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-I) |
|
| Environmental |
| Operating Temperature |
32 to 104°F (0 to 40°C) |
| Operating Humidity |
0 to 85% |
|
| Power |
| Batteries |
1 x LP-E17 Rechargeable Lithium-Ion Battery Pack |
| AC Power Adapter |
AC-E6N with DR-E18 (Optional) |
|
| Kit Lens 1 |
| Focal Length KL1 |
18 to 55mm (35mm Equivalent Focal Length: 28.8 to 88mm) |
| Maximum Aperture KL1 |
f/4 to 5.6 |
| Minimum Aperture KL1 |
f/22 to 32 |
| Angle of View KL1 |
74° 20′ to 27° 50′ |
| Maximum Magnification KL1 |
0.25x |
| Minimum Focus Distance KL1 |
9.84″ / 25 cm |
| Optical Design KL1 |
12 Elements in 10 Groups |
| Diaphragm Blades KL1 |
7, Rounded |
| Focus Type KL1 |
Autofocus |
| Image Stabilization KL1 |
58 mm (Front) |
| Image Stabilization Notes KL1 |
YES |
| Package Weight KL1 |
2.6 lb |
| Box Dimensions (LxWxH) KL1 |
8.7 x 6.5 x 5.8″ |
|
