| Camera |
| Shutter Speed |
Electronic Front Curtain Shutter – /4000 Up to 30 Seconds
Electronic Shutter – 1/16000 Up to 30 Seconds in Manual Mode
Electronic Shutter – 1/16000 Up to 30 Seconds in Time Mode
Electronic Shutter – 1/8000 Up to 30 Second |
| Built-in ND Filter |
None |
| White Balance |
Custom
Fluorescent (White)
Auto
Cloudy
Daylight
Flash
Shade
Tungsten |
| Shutter |
Electronic Shutter |
|
| Imaging/ Image Sensor |
| Aspect Ratio |
3:2 |
| Sensor Type |
35.9 x 23.9 mm (Full-Frame) CMOS |
| Image File Format |
C-RAW
HEIF
JPEG
RAW |
| Sensor Resolution |
Effective: 24.2 Megapixel |
| ISO Sensitivity |
Photo/Video – 100 to 102,400 (Extended: 50 to 204,800) |
| Bit Depth |
14-bit |
| Image Stabilization |
5-Axis (Video Only)
Sensor-Shift |
|
| Lens |
| Lens Mount |
Canon RF |
| Focus Type |
Auto and Manual Focus |
|
| Shutter |
| Self Timer |
2/10-Second Delay |
|
| Focus & Optics |
| Focus Mode |
Manual Focus
Single-Servo AF
Continuous-servo AF (C) |
| Autofocus Points |
Photo Phase Detection: 4897
Video Phase Detection: 4067 |
| Autofocus Sensitivity |
-6.5 to +21 EV |
|
| Viewfinder & Display |
| Viewfinder |
Built-In Electronic (OLED) |
| Viewfinder Coverage |
100% |
| Viewfinder Eye Point |
22 mm |
| Viewfinder magnification |
Approx. 70x |
| Viewfinder resolution |
2,360,000 Dot |
| Display Type |
Articulating Touchscreen LCD |
| Display Screen |
3.0″ |
| Display Resolution |
1,620,000 Dot |
| Diopter Adjustment |
-4 to +1 |
|
| Exposure Control |
| Exposure Modes |
Aperture Priority
Manual
Program
Shutter Priority |
| Metering Method |
Center-Weighted Average
Evaluative Metering
Partial Metering
Spot metering |
| Metering Range |
-3 to 20 EV |
| Exposure Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps) |
| Continuous Shooting |
Electronic Shutter – Up to 40 fps for up to 120 Frames (JPEG) / 56 Frames (Raw)
Electronic Shutter – Up to 6 fps for up to 1000 Frames (JPEG) / 1000 Frames (Raw) |
| Interval Recording |
Yes |
|
| Recording |
| Video Recording |
Yes, NTSC |
| Recording Modes |
H.264/H.265/MP4 4:2:2 10-Bit 1920 x 1080 up to 23.98/25/29.97/50/59.94/100/120/150/180 fps
H.264/H.265/MP4 4:2:2 10-Bit UHD 4K (3840 x 2160) up to 23.98/25/29.97/50/59.94 fps |
| Gamma Curve |
Canon Log 3
HDR-PQ |
| External Recording Modes |
None |
|
| Audio |
| Built-In Microphone |
Stereo |
|
| Connectivity |
| Wireless |
2.4 GHz Wi-Fi (802.11b/g)
Bluetooth |
| GPS |
No |
|
| Flash |
| Built-in Flash |
No |
| Dedicated Flash System |
eTTL |
| External Flash Connection |
Hot Shoe |
| Flash Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps) |
| Flash Modes |
Auto |
| Max Sync Speed |
1/200 Second |
|
| Performance |
| Tripod Mounting Thread |
1 x 1/4″-20 Female (Bottom) |
|
| Interface |
| Video Connectors |
1 x Micro-HDMI Output |
| Audio Connectors |
1 x 1/8″ / 3.5 mm TRRS Headphone/Mic Headphone Output on Camera Body
1 x 1/8″ / 3.5 mm TRS Stereo Microphone Input on Camera Body |
| Other I/O |
1 x USB-C (USB 3.2 / 3.1 Gen 2) |
| Memory Card Slot |
Single Slot: SD/SDHC/SDXC |
|
| Environmental |
| Operating Temperature |
32 to 104°F / 0 to 40°C |
| Operating Humidity |
0 to 85% |
|
| Power |
| Battery Type |
1 x LP-E17 Rechargeable Lithium Polymer |
|
| Physical |
| Dimensions |
5.22 x 3.39 x 2.76″ / 132.59 x 86.11 x 70.1 mm |
| Weight |
0.9 lb / 414 g (Body Only)
1.0 lb / 461 g (With Battery, Recording Media) |
|
| Kit Lens 1 |
| Focal Length KL1 |
24 to 50mm |
| Maximum Aperture KL1 |
f/4.5 to 6.3 |
| Angle of View KL1 |
84° |
| Maximum Magnification KL1 |
11x |
| Minimum Focus Distance KL1 |
11.8″ / 30 cm |
| Optical Design KL1 |
8 Elements in 8 Groups |
| Diaphragm Blades KL1 |
7 |
| Focus Type KL1 |
Autofocus |
| Image Stabilization KL1 |
Yes |
| Filter Size KL1 |
58 mm (Front) |
| Dimensions (ø x L) KL1 |
2.7 x 3.7″ / 68.6 x 94 mm |
| Weight KL1 |
7.4 oz / 210 g |
| Package Weight KL1 |
0.81 lb |
| Box Dimensions (LxWxH) KL1 |
7.6 x 4.9 x 4.8″ |
|
| Camera Filters |
|
|
| Packaging Information |
| Box Dimensions (LxWxH) |
11.6 x 7.5 x 6.1″ |
|
